Rigid Box Dieline

Rigid Box Dieline Description

This dieline represents the structural layout for a rigid box, typically used for luxury packaging such as electronics, cosmetics, or gift items. The dieline includes precise cut lines, fold lines, and glue areas, ensuring accurate and efficient assembly.

Key Features:

• Material: Greyboard (typically 1.5mm – 3mm thick), covered with printed or textured paper wrap
• Components:
• Base tray and lid with corresponding dimensions and depth
• Spine (if applicable) for hinged or magnetic closure versions
• Glue flaps clearly marked for wrap application
• Lines:
• Solid lines indicate die cuts
• Dotted/dashed lines indicate folds or scores
• Shaded/marked zones show glue areas or wrap margins
• Wrap Allowance: [Usually 15–20mm] wrap margin around all outer edges for neat paper application
• Bleed Area: Include [3–5mm] bleed to prevent white edges after trimming
• Assembly Notes: Requires hand-wrapping and mounting of greyboard pieces onto the wrap sheet

Use Case: Ideal for premium branding, gift packaging, or product launches that require a sturdy, elegant presentation.
