For this project, you will implement a program to encode text using Huffman coding. Huffman coding is a method of lossless (the original can be reconstructed perfectly) data compression. Each character is assigned a variable length code consisting of ’0’s and ’1’s. The length of the code is based on how frequently the character occurs; more frequent characters are assigned shorter codes.

The basic idea is to use a binary tree, where each leaf node represents a character and frequency count. The Huffman code of a character is then determined by the unique path from the root of the binary tree to that leaf node, where each ’left’ accounts for a ’0’ and a ’right’ accounts for a ’1’ as a bit. Since the number of bits needed to encode a character is the path length from the root to the character, a character occurring frequently should have a shorter path from the root to their node than an “infrequent” character, i.e. nodes representing frequent characters are positioned less deep in the tree than nodes for infrequent characters.

The key problem is therefore to construct such a binary tree based on the frequency of occurrence of characters. A detailed example of how to construct such a Huffman tree is provided here: Huffman_Example.pdf

Note:

• You must provide test cases for all functions.
• Use the given names for specified functions, exactly as they appear in the assignment.
• Use descriptive names for data structures and helper functions.

Source Files

Start with the source files provided to you as part of GitHub Classroom.

Functions

The following bullet points provide a guide to implement some of the data structures and individual functions of your program. You should develop incrementally, building test cases for each function as it is implemented.

Count Occurrences: cnt_freq(str)

• Implement a function called cnt_freq(str) that accepts a string and returns an array that indicates the number of occurrences of each character in the string. Use an array data structure of size 256 for counting the occurrences of characters. This will provide efficient access to a given position in the list. You can use the Python ord function to map characters (or, more precisely, strings of length one) to numeric values. You should discard all values larger than 255. (These numbers will then be ASCII codes.) This function should return the 256 item list with the counts of occurrences. There can be issues with extra characters in some systems.
• Suppose the file to be encoded contained: ddddddddddddddddccccccccbbbbaaff
• Numbers in positions of freq counts [96:104] = [0, 2, 4, 8, 16, 0, 2, 0]
• For an empty file, this function should return a list of size 256 filled with all 0s.

Data Definition for Huffman Tree

A Huffman Tree or HTree is a binary tree of HNode's and HLeaf's. (Note: None is not a legal HTree.)

• An HNode contains an occurrence count for that tree, a character, and a left and a right HTree. An HLeaf contains only a character and an occurrence count.

(Note: The character in the HNode isn't really necessary… but having a character here, and using it in the way specified in the PDF, makes it easier to grade the submissions, by ensuring that there's only one way to build the tree.)

Build a Huffman Tree

Since the code depends on the order of the left and right branches take in the path from the root to the leaf (character node), it is crucial to follow a specific convention about how the tree is constructed. To do this we need an ordering on the Huffman nodes.

• Start by defining the tree_lt(a, b) function that accepts two HTrees and returns true if the occurrence count of the first is less the occurrence count of the second OR if the two occurrence counts are equal and the character contained at the root of the first tree is less than the character contained at the rood of the second tree. Note that this refinement (checking the characters) does not affect the overall compression associated with huffman coding, but it ensures that the ordering is a total ordering (at least for sets of trees where each tree's root character occurs at most once, which is the case for our tree lists).
• Next, define the HTList data definition, which represents a linked list of HTrees. This must include an HTNode (N.B.: don't confuse this with HNode, the HTree node class). It must be possible to directly construct a list as e.g. HTNode(a,HTNode(b,HTNode(c,None))) where a, b, and c are HTrees.
• Develop the basetreelist function, that accepts an array of character counts (as returned by cnt_freq) and returns an HTList containing 256 HLeaf's, one for each ASCII code. These should be in order from 0 up to 255, where 0 is the first element of the list and 255 is the last.
• Develop the treelistinsert function, that takes an HTList of HTrees that is sorted in the order specified by tree_lt (that is, the occurrence count of the first tree is less than or equal to the occurrence count of the second tree in the list, and so forth), and another HTree, and inserts it in the list at its correct location so that the resulting HTList is still sorted. The function must return the new list.
• Develop the initialtreesort function, that accepts an unsorted list and constructs and returns a sorted list by inserting the nodes from the unsorted list one at a time into an initially empty sorted list.
• Develop the coalesce_once function, that accepts a sorted HTList of length 2 or more, and forms a new list by joining the first and second node together into a new HNode and inserting that new HNode into the list containing the remaining elements. The occurrence count of the new node should be the sum of the two original ones, and the left and right fields of this node should refer to the original trees. At the end, the list should be shorter by one, because we're taking two elements off of the list and inserting one. This function must return the new list.
• Develop the coalesce_all function, that accepts a sorted HTList of length one or more and calls coalesce_once repeatedly until the list contains only a single HTree, then returns that one HTree.

This single tree is what we call the Huffman Tree. Its occurrence count should be the number of characters in the original file, and each subtree should have roughly the same number of characters (or as close as we can get, given our other constraints). This will mean that common characters are found along short paths, and that uncommon characters are found along long paths. This gives rise to our encoding scheme, which is to represent each character as a path down from the root of this tree to the leaf containing the given character.

In fact, what we really have now is the decoding tree; if we are given a sequence such as "left left right left right right left", we can start at the root and follow left and right paths to until we get to a leaf node, which represents a character in the stream; to continue decoding, we start at the top again.

Next, we need to map this decoding tree into an encoding tree; to do this, we must identify for each character the path that leads to that character.

This will consist of a function that follows the template for an HTree, with two accumulators. One is an array of 256 strings, which will wind up being our map from characters to their encodings. The other is a string containing ones and zeros, that represents the path taken to get from the root to this particular node; a zero represents a trip down the left branch, and a one a trip down the right branch. So, for instance, if a left left right path leads to the character Q, then in location 81 of the array (ord('Q') == 81), we would put the string "001".

• Develop the buildencoderarray function, that performs this construction.
• Develop the function encodestringone, that accepts a string and an encoder array and constructs the string (containing entirely ones and zeros) formed by appending the encodings of each of the characters in the string.
• Develop the function bitstochars, that accepts a string of ones and zeros and converts it to a new string that is 1/8 as long by taking each 8-char substring of ones and zeros, converting it to the corresponding integer in the range 0-255, and then using the chr function to produce a single character of the output string. The input string's length is unlikely to be divisible by eight; you can pad the string with zeros to get it up to the final length.
• Finally, tie it all together with a huffmancodefile function that accepts a source and target file path, reads the input file, constructs a huffman tree, maps this to an encoding tree, uses the encoding tree to encode the contents of the input file, converts it to the char representantion, then writes this to the new file (replacing any file that was existing at this path).
