PARAMETRIC BUTTRESS THREAD TURNING CYCLE

Professional Buttress Thread Machining From Simple Editable Parameters

Turn complex buttress-thread programming into a reusable parametric CNC lathe cycle.

The Parametric Buttress Thread Turning Cycle uses synchronized threading passes to rough the thread root to the required minor diameter, then progressively generates the 45° buttress flank.

Define the thread. Run the cycle. Reuse it for the next job.

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━

⚙️ CYCLE CAPABILITIES

✅ 2-axis X/Z CNC lathe machining

✅ G33 / synchronized threading strategy

✅ Parametric major diameter

✅ Parametric minor diameter

✅ Editable thread pitch / lead

✅ Editable thread length

✅ Adjustable radial depth per roughing pass

✅ Adjustable 45° flank step

✅ Multi-pass root roughing

✅ Automatic minor-diameter finishing pass

✅ Progressive 45° buttress flank generation

✅ Selectable flank direction

✅ Automatic retract and repositioning

✅ Designed around a 5 mm full-round R2.5 grooving tool

✅ Simple reusable machining parameters

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━

🔩 MACHINING STRATEGY

The cycle automatically performs the operation in two controlled stages.

1 — ROOT ROUGHING

Multiple synchronized threading passes progressively machine from the major diameter down to the programmed minor diameter.

2 — 45° BUTTRESS FLANK

Once the root is complete, the cycle progressively shifts the tool in X and Z to generate the required 45° flank.

Each calculated position receives a complete synchronized threading pass.

ROOT → MINOR DIAMETER → 45° FLANK → FINISHED BUTTRESS PROFILE

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━

🚀 FANUC G65 CUSTOM CANNED CYCLE

The Fanuc version includes a compact G65 call controlling the complete operation from one programmable line.

Example:

G65 P9941 A60. B52. C20. I60. J0.5 K0.5 H5. R1. S100. Z5.

Simply edit the required thread dimensions and machining values.

The complete machining logic remains stored inside the custom cycle.

One G65 line. One reusable buttress-thread cycle.

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━

📦 COMPLETE DOWNLOAD PACKAGE

Included:

✅ Parametric Buttress Thread Turning Cycle

✅ Fanuc G65 custom canned-cycle version

✅ Example main program

✅ Complete parameter mapping

✅ Siemens version

✅ Haas version

✅ Mitsubishi version

✅ Mazak EIA/ISO version

✅ Heidenhain CNC PILOT version

✅ User guides

✅ Setup information

✅ First-run and prove-out guidance

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━

💡 WHY USE THIS CYCLE?

Need a different diameter?

Change the diameter.

Different pitch?

Change the pitch.

Different thread length?

Change the length.

Want finer flank generation?

Change the flank step.

The machining strategy stays inside the cycle.

Less repetitive programming. Faster setup. Reusable CNC automation.

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━

🛒 AVAILABLE AS A STANDALONE CYCLE OR INSIDE CNC AUTOMATION PRO

Purchase the Parametric Buttress Thread Turning Cycle as a standalone downloadable module, or access it through CNC Automation Pro together with 100s of custom canned cycles, CNC macros, programming modules, software and training resources.

PARAMETRIC BUTTRESS THREAD TURNING CYCLE

Define the thread. Run the cycle.

MacroMill CNC

www.macromillcnc.com
