JaySmitt Labs Subdivision ToolKit

Turn a bare parcel boundary into a complete, labeled subdivision plat — all inside AutoCAD.

The JaySmitt Labs Subdivision ToolKit is a suite of AutoLISP commands built by people who actually lay out subdivisions. Draw roads, cul-de-sacs, knuckles, elbows, roundabouts, 3-way and 4-way intersections, then divide blocks into lots, number them, and label every bearing, distance, and curve — all driven by one set of design standards you configure once.

WHAT'S INCLUDED

• Road tools: straight, curved, and perimeter roads, boulevards, through-roads, and clean intersections
• - Intersection tools: 3-way, 4-way, cross roads with radius returns
• - Cul-de-sacs, knuckles, elbows, roundabouts, and road circles
• - Lot tools: lot division, lots by acreage, arc lots, block and lot numbering, total lot counts
• - Labeling: bearings and distances (metes and bounds), curve tables, acreage labels
• - Design Settings dialog: set your standards once (road widths, radii, layers, text styles) and every command follows them

WHAT YOU GET

• Complete toolkit (v1.3) ready to load with APPLOAD
• - Full illustrated PDF manual
• - Every command demonstrated on our YouTube channel

REQUIREMENTS

• AutoCAD (full version, Windows 64-bit). Not compatible with AutoCAD LT versions without LISP support.

Support: smitt@jaysmittlabs.com
