2D Boundary Wall Plan & Elevation – AutoCAD DWG

This professionally drafted 2D Boundary Wall Drawing includes both plan and elevation, designed for residential and commercial properties. The drawing is clean, well-layered, and fully editable in AutoCAD, making it ideal for site execution, approval drawings, and client presentations.

The boundary wall design follows practical construction standards, with clear dimensions, gate opening layout, and elevation detailing suitable for modern and traditional houses.

🔹 What’s Included

• ✔ Boundary Wall Plan (Top View)
• ✔ Boundary Wall Elevation
• ✔ Gate opening clearly shown
• ✔ Proper dimensions & alignment
• ✔ Organized layers for easy editing
• ✔ Ready for plotting and site use

🔹 Key Features

• ✔ 100% Editable AutoCAD DWG
• ✔ Clean, professional drafting
• ✔ Scalable to any plot size
• ✔ Suitable for approval & construction
