Foundation & Load-Path Coordinator

Foundation & Load-Path Coordinator

Bring greater clarity and consistency to your foundation drawings with a convenient LISP + DCL drafting toolkit. Place footings, posts, and beams, trace load paths, and flag terminal endpoints that need support review—all from one organized dialog.

Features include:

• Place square or circular footings with centered posts.
• Add posts and bearing-point markers.
• Draw beam outlines with size labels.
• Trace load paths with directional arrows and user-entered load labels.
• Check terminal endpoints for nearby bearing markers using an adjustable tolerance.
• Insert coordination schedules and structural review notes.
• Create dedicated drafting layers and control labels, centerlines, and review flags.

Your download includes: LISP program, DCL dialog file, setup instructions, product cover, and dialog preview.

A practical addition to your residential CAD workflow for preparing clearer drawings and coordinating items that require further review.

Preliminary drafting and coordination aid only. The program does not calculate structural loads or verify member capacity. Endpoint checks screen proximity only; structural and geotechnical design require qualified professional verification.
