Printable Staggered Shoe Tower Plans, Angled Shoe Rack Woodworking Plan PDF, Drawer Base + Tray Top, Entryway Shoe Storage DIY, Letter or A4

Print at home: US Letter 8.5x11 in or A4 (international paper size).

A sculptural shoe tower: 10 10° angled shelves alternate left and right of a center spine, half a level apart, so every pair is on display and easy to grab. Each shelf is held at BOTH ends by glued + screwed cleats (spine + rear post) and has a heel-stop rail. Below is a drawer on full-extension slides with a scooped pull; on top, a lipped tray for keys and sunglasses. 24" wide, anchored to the wall, imperial + metric, with a full-size tier template.

This isn't a photo with a parts list. Every dimension comes from a parametric 3D model, and the cut list is checked against it by a second, independent calculation, so the parts actually fit. Finished size: 24" W x 11-1/2" D x 58" H (610 mm x 292 mm x 1473 mm).

WHAT'S INCLUDED (24 pages, 4 printable PDFs: full color + Ink-Saver, each in US Letter and A4):

• Overview with overall dimensions + blueprint front/side/top views

• Skill level, build time and a cost estimate (about $160–$190 in materials, 2026 US prices)

• Tools list and printable shopping list (lumber, sheets, hardware, finish)

• Verified cut list: 19 lettered items / 60 pieces, inches + millimeters

• Board cut diagrams and plywood sheet layouts with kerf allowance

• Exploded view with part letters

• 6 step-by-step assembly pages, each with a 3D render of plan

• Printable FULL-SIZE 10° tier marking template with a scale check

• Finishing guide, size and style variations, troubleshooting

• Verification report (the 3D model's automatic checks)

• Safety & disclaimer page, version number and corrections contact

DETAILS:

• Skill level: Beginner+ · Build time: 1–2 weekends

• Instant download: 4 printable PDFs (full color + Ink-Saver). Print at home: US Letter 8.5x11 in or A4 (international paper size)

• Imperial and metric measurements throughout

• Uses real lumber sizes (a 2x4 is 1-1/2" x 3-1/2"; 3/4" plywood is 23/32")

• Version 1.0. Free updated PDF if a correction is ever made

All product images and plan illustrations are 3D renders of the plan's own 3D model (labeled '3D render of plan'), not photos of a finished build. No AI image generators are used. AI disclosure: CD Green Studio made this plan with the help of AI tools (the 3D model code, cut list checks, drawings and written instructions were produced with AI assistance under our direction).

This is a digital download of a woodworking PLAN: no physical item or lumber is shipped. Build at your own risk; check all measurements and local codes. For personal use: you may sell furniture you build from it, but not the plan itself.

INK-SAVER EDITION: same plan with light page headers so it prints fast and cheap on a home printer.

Look for Yogi, our Studio Supervisor, napping in your plan. In memory of our nap-loving shop dog.
