CORNER-RADIUS RECTANGULAR POCKET ROUGHING & FINISHING CYCLE
⚙️ PARAMETRIC CORNER-RADIUS RECTANGULAR POCKET ROUGHING & FINISHING CYCLE
Professional parametric rectangular pocket machining with automatic helical entry, calculated corner-radius roughing and complete wall finishing.
Turn repetitive pocket programming into one compact, reusable CNC cycle. Define the pocket size, corner radius, cutter, depth and machining conditions — the cycle automatically calculates the complete roughing and finishing strategy.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚙️ CYCLE CAPABILITIES
✅ 3-axis CNC milling
✅ Programmable pocket length and width
✅ Programmable internal corner radius
✅ Automatic helical entry
✅ Automatic multiple Z-depth machining
✅ Alternating raster roughing
✅ Automatic rounded-corner X limits
✅ Automatic equalized XY stepover
✅ Programmable rough wall stock
✅ Automatic cutter-radius calculation
✅ Automatic tool-center geometry
✅ Complete corner-radius wall finishing
✅ Automatic final-depth control
✅ Adjustable pocket X/Y center
✅ Adjustable cutter diameter
✅ Adjustable feeds and spindle speed
✅ Reusable for different pocket sizes and cutters
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🌀 AUTOMATIC HELICAL ENTRY
Every new depth begins with a controlled helical entry. The cutter progressively moves down in Z while performing circular X/Y interpolation, eliminating the need to manually program repeated entry movements.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
↔️ AUTOMATIC ROUGHING
The cycle automatically roughs the pocket using alternating left-to-right and right-to-left passes. As the cutter enters the corner-radius areas, the X cutting limits are automatically reduced to follow the programmed pocket geometry.
The programmed stepover is used as the maximum value and automatically equalized across the available pocket width for a consistent roughing pattern.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🎯 ROUGHING + FINISHING
A programmable wall allowance is left during roughing. After each roughing level, the cycle automatically machines the complete finished rectangular profile including all four internal corner radii.
One cycle handles:
✅ Helical entry
✅ Raster roughing
✅ Corner-radius calculations
✅ Wall stock
✅ Complete finishing contour
✅ Multiple depth levels
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🎛️ SIMPLE EDITABLE INPUTS
✅ Pocket length X
✅ Pocket width Y
✅ Corner radius
✅ Total depth
✅ Depth per pass
✅ Tool diameter
✅ Maximum XY stepover
✅ Rough wall stock
✅ Helix radius
✅ Safe Z
✅ Rapid approach Z
✅ Helix start clearance
✅ Helical entry feed
✅ Cutting feed
✅ Spindle RPM
✅ Pocket center X/Y
✅ Top of part Z
Change the dimensions. Change the cutter. Change the depth. Run the cycle again. The machining strategy automatically recalculates.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📦 COMPLETE DOWNLOAD PACKAGE
✅ Controller-ready CNC cycle
✅ Editable parameter program
✅ Dedicated user guide
✅ Parameter explanation
✅ Setup and prove-out guidance
✅ Individual controller download packages
🎮 SUPPORTED CONTROLLERS
Fanuc • Siemens • Heidenhain • Okuma • Mitsubishi • Haas • Mazak • GSK • Fagor
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
💡 WHY USE THIS CYCLE?
No manually programming dozens of pocket passes.
No manually calculating rounded-corner roughing limits.
No manually calculating cutter-center radii.
No rebuilding the program when pocket dimensions change.
Less repetitive programming. Faster setup. Consistent machining. Reusable CNC automation.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🛒 AVAILABLE STANDALONE OR INSIDE CNC AUTOMATION PRO
Available as a standalone downloadable cycle or through CNC Automation Pro together with 100s of custom canned cycles, CNC macros, software, ebooks and CNC training resources.
MacroMill CNC
www.macromillcnc.com
