Solar LED wall light with PIR

Description

The IP65 solar LED wall light with PIR sensor requires no connection to the electrical grid.

The solar LED wall light with PIR sensor remains off and automatically activates when a heat source moves in front of the switch within its detection range (approximately 3 to 5 meters). This feature helps extend the product's lifespan and offers greater energy savings.

It is equipped with a 3.7V 1200mAh lithium-ion battery that charges using solar energy. The full charging time is 6 hours, and the operating time is approximately 8 to 10 hours.

Technical File

Product Code: LM-035

Light Temperature: Cool White

Dimensions (mm): 55 x 108 x 127

Height: 55.0 mm

Length: 127.0 mm

Width: 108.0 mm

LED Type and Quantity: SMD2835

Construction: Aluminum / PC

Beam Angle (°): 270

Installation: IP65

Voltage: 3.7V 1200mAh

Estimated Lifespan: 40,000 hours

Dimmable: No

Operating Frequency (Hz): 50 / 60

Start Time (s): 0.2

Certifications: CE / ROHS / ISO9001

Terminal Type: Terminal

Operating Temperature Range (°C): -20 to +60

Switching Cycles: 100,000

Diffuser: Transparent

Weight (g): 200

Half-Year Lifetime (3h/day): 36.52

Half-Year Lifetime (5h/day): 21.91

Half-Year Lifetime (8h/day): 13.69

CCT Type: Single

Applicable Standards:

EN 55015:2013

EN 61547:2009

IEC 62321-3-1:2013

IEC 62321-5:2013

IEC 62321-4:2013

IEC 62321-6:2015

IEC 62321-7-1:2015

IEC 62321-7-2:2017
