Nano-Bubble Water Fuel GMS: Gas Management and Ignition System

Nano-Bubble Water Fuel GMS: Gas Management and Ignition System
Stanley A. Meyer's Control Cards, Distributors, Injectors and Coils in Modern Terms, 2026 Edition
Daniel Donatelli — Secure Supplies Group / Donatelli LLC

A card-by-card description of the Gas Management System (GMS) in Stanley A. Meyer's patents and replications, followed by a practical survey of modern ignition and switching hardware for builders adapting the concept to nano-bubble water fuel experiments. The first part explains the function of the variable pulse frequency generator, gate pulse generator, analog voltage generator and control cards, the TPS throttle card, the phase-lock circuit card and the VIC matrix card, then covers the dual-stack distributor and the two-in-one injector concept. The second part compares off-the-shelf GaN and MOSFET switch boards for Speeduino and Megasquirt ECUs, commercial ignition coils and transformer options against a VIC-equivalent specification, with prices and sources current to 2026, and a parts-matching specification for round-bobbin coils. An appendix documents the PC9XE sequential gate card: where it sits in the control chain, its inputs and outputs, and replication notes. Provided for informational and educational purposes; the author makes no performance claims.

Formats included: EPUB and PDF. Instant download after purchase.

Topics: gas management system; Stanley Meyer; VIC coil; ignition coils; Speeduino Megasquirt; GaN switch boards; sequential gate circuit

Provided for informational and educational purposes; the author makes no performance claims.

© 2026 Daniel Donatelli. All rights reserved.
