Permit Drawing QC Manager Pro

Review residential permit drawings faster and more consistently with Permit Drawing QC Manager Pro—an AutoLISP and DCL quality-control tool developed from an AutoCAD 2002-compatible foundation.

This professional drafting assistant scans selected drawing and sheet conditions, organizes the findings into clear PASS, INFO, REVIEW, and HOLD categories, and calculates a simple permit-readiness score to help you prioritize corrections before submitting a drawing set.

FEATURES

• Reviews expected residential sheet categories

• Detects model-space objects placed on Layer 0

• Flags possible color and linetype property overrides

• Identifies missing or unresolved external-reference paths

• Searches for candidate title-block inserts

• Counts compatible coordination data and issue markers

• Produces a simple 0–100 readiness score

• Creates a formatted review package inside the drawing

• Exports the latest findings as a plain-text report

• Uses customizable project and jurisdiction information

SHEET CATEGORIES

• Cover sheet and code data

• Site plan

• Floor plans

• Roof plan

• Exterior elevations

• Building sections

• Structural and foundation sheets

• Electrical and energy sheets

COMMANDS

PERMITPACKAGE — Runs the complete setup, review, and drawing-package workflow

ONECLICKPERMIT — Shortcut for the complete workflow

PRSETUP — Opens the project and checklist settings

PRCHECK — Runs the review without placing graphics

PREXPORT — Exports the latest findings to a text report

YOUR DOWNLOAD INCLUDES

• PermitReviewPackage.lsp

• PermitReviewPackage.dcl

• Installation guide

• Command reference

• Compatibility notes

• Single-user commercial license

• Disclaimer and support documents

• Changelog

COMPATIBILITY

Developed from an AutoCAD 2002-compatible AutoLISP and DCL foundation. The software requires an AutoCAD edition and environment that support AutoLISP and DCL.

Because AutoCAD versions, configurations, language packs, and security settings can vary, buyers should test the software on a backup copy of a drawing before using it on production work.

IMPORTANT LIMITATIONS

Permit Drawing QC Manager Pro is a drafting quality-control assistant. It does not determine code compliance, certify a drawing set, guarantee permit approval, or replace professional architectural, engineering, zoning, accessibility, energy, life-safety, or agency review.

The readiness score is a review-priority indicator—not a compliance rating or prediction of permit approval. Permit requirements must always be confirmed with the authority having jurisdiction and the responsible licensed professionals.

Commercial Edition Launch Price: $49

Catch common drawing-set issues earlier, organize your permit review, and approach every submission with a more consistent quality-control workflow.
