Complete Ohm’s Law & Kirchhoff Circuit Experiment Dataset

Usefull for First Year Engineering Students

Real laboratory measurements collected from a university electronics practical session.

Includes raw data and simulation values for:

• Ohm’s Law Test (measured V–I behavior of resistors & light bulb load)
• Voltage Divider Circuit (expected vs measured node voltages)
• Current Divider Circuit (expected vs measured branch currents)

All data is neatly arranged in Excel with labeled columns and experiment notes.

Perfect for:

• Homework / lab report preparation
• Teaching materials
• Circuit analysis validation
• Practice with error analysis or plotting

Contents:

• 1 Excel file (4 experiment sheets)
• Simulation vs measured values
• Light bulb load behavior
• Divider circuits with R1/R2 values provided

Benefits

• Save time recreating basic EE experiments
• Ready for graphing, report writing, or circuit comparison
• Real-world measurement noise included (good for analysis practice)
