Downlight LED 5W 2700K (Warm White)

1. Product Identification

• Product Code: LM-001-C10-5W-WW
• Commercial Name: Downlight LED 5W Ø60x77mm Warm White
• Category: Technical Lighting – Recessed
• Application: Indoor residential or commercial lighting where soft and warm light is desired.

2. Technical Specifications

• Power Consumption: 5.0 W
• Energy Usage: 5.0 kWh/1000h
• Halogen Equivalent: 45 W
• Color Temperature: 2700 K (Warm White)
• Fixed CCT: Yes (only 2700 K)
• Luminous Flux: 421 lumens
• Luminous Efficacy: 84 lm/W
• Beam Angle: 60º
• CRI (Color Rendering Index): ≥80
• R9 Index: 12
• CRI Range: Minimum 95 / Maximum 22
• Chromaticity Coordinates: x = 0.437 / y = 0.405
• LED Type: Epistar LED
• Dimmable: No
• Power Factor (PF): 0.9
• Insulation Class: Class I
• Ingress Protection (IP): IP65 – dust-tight and water jet resistant
• Impact Protection (IK): IK07 – high mechanical resistance
• Operating Frequency: 50/60 Hz
• Input Voltage: 85–265V AC
• Start Time: 0.2 s
• Light Directionality: Directional
• Energy Class: F

3. Construction

• Materials: Aluminium and glass
• Diffuser: Transparent
• Socket / Connection: Terminal
• Dimensions: Diameter 60 mm x Height 77 mm
• Weight: 220 g

4. Durability

• Estimated Lifespan: 40,000 hours
• Switching Cycles: 100,000
• Operating Temperature Range: -20 °C to +60 °C
• Estimated Lifespan (by daily usage):
• 3h/day: 36.52 years
• 5h/day: 21.91 years
• 8h/day: 13.69 years

5. Certifications and Technical Standards

• Certifications: CE, RoHS, ISO9001
• Applicable Standards:
• IEC 62321:2008
• EN 55015:2006
• EN 61000-3-2:2006
• EN 61000-3-3:2008
• EN 61547:2009
• EN 60598-1:2008
• EN 61347-1:2008
• EN 61347-2-13:2006
• EN 62031:2008
