Remodel Field Measurement Reconciler

Remodel Field Measurement Reconciler

Catch measurement differences before they become drafting mistakes. This AutoLISP + DCL tool helps architects, designers, engineers, and remodelers compare field measurements with CAD distances and organize items that need review.

Features include:

• Compare two picked CAD points against a field measurement.
• Set a tolerance to identify PASS or REVIEW results.
• Convert field values into drawing units using a custom conversion factor.
• Choose planar or true 3D distance comparisons.
• Add location labels and field notes.
• Place color-coded measurement tags.
• Save comparison records inside the drawing.
• Export CSV reports for project coordination.

Your download includes: LISP program, DCL dialog file, installation instructions, and sample verification steps.

Command: RFMR

Please note: Comparisons are saved snapshots and do not update automatically when geometry changes. The tool does not resize or correct drawing objects. Designed for full Windows AutoCAD with Visual LISP and DCL; live version compatibility testing is pending.
