Appliance Diagnostic Guides: 7 Step-by-Step Troubleshooting Flowcharts

Fix the problem or know exactly what to tell the repair tech. This pack walks you through the seven most common home appliance failures in order, from the quickest checks to the more involved ones:

- Washer won't drain

- Washer won't spin

- Dryer runs but doesn't heat (electric and gas)

- Refrigerator not cooling (freezer still cold)

- Dishwasher not draining or not cleaning

- Electric oven won't heat

- Ice maker not making ice

Plus a one-page multimeter primer.

Each guide lists the symptoms, then gives the steps in order, typical multimeter checks, and the parts most likely to be at fault. Written by a retired military veteran who teaches technical skills the way the military does: one checkable step at a time.

Safety and disclaimer: For general educational purposes only. Always disconnect power, water, and gas before you work. Some jobs (sealed refrigerant systems, gas lines, microwave high-voltage circuits) belong to licensed or certified professionals, and the guides say where. Values are typical ranges, so always confirm against your model's tech sheet. Not affiliated with any appliance manufacturer. Opening an appliance may void its warranty.

Digital download. No physical item ships.
