MULTI-GROOVE V-PULLEY MACHINING CYCLE
PARAMETRIC MULTI-GROOVE V-PULLEY MACHINING CYCLE
Complete Multi-Groove V-Pulley Machining & Automatic Part-Off From One Reusable CNC Cycle
Machining multiple V-pulley grooves normally requires repeated grooving operations, individual groove positioning, roughing, flank finishing and a separate part-off sequence.
The Parametric Multi-Groove V-Pulley Machining Cycle combines the complete operation into one reusable CNC machining cycle.
Enter the required pulley dimensions, V-groove geometry, groove quantity, groove spacing and part-off position — the cycle automatically controls the complete machining process.
Machine the groove. Repeat the pattern. Finish the pulley. Part off automatically.
Define the job. Run the cycle. Reuse it.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚙️ CYCLE CAPABILITIES
✅ 2-axis X/Z CNC lathe machining
✅ Parametric V-pulley machining
✅ Automatic multiple V-groove machining
✅ Editable pulley outside diameter
✅ Editable groove root diameter
✅ Editable groove bottom width
✅ Editable V-groove angle
✅ Editable first groove position
✅ Editable number of V grooves
✅ Editable center-to-center groove spacing
✅ Editable final part-off position
✅ Automatic groove-position calculation
✅ Automatic multi-groove progression
✅ Automatic mirrored V-flank machining
✅ Progressive groove roughing
✅ Full-retract peck machining
✅ Complete tool withdrawal after every peck
✅ Controlled re-entry into the machined groove
✅ Automatic roughing progression
✅ Automatic finishing of both V flanks
✅ Automatic progression to the next groove
✅ Independent roughing and finishing cutting conditions
✅ Automatic final part-off operation
✅ Full-retract peck-style part-off
✅ Part-off begins only after all V grooves are completed
✅ Reusable for different pulley diameters
✅ Reusable for different groove quantities
✅ Reusable for different groove spacing
✅ Reusable for different V angles
✅ Designed for repetitive production
✅ Multi-controller packages available
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🔵 COMPLETE V-PULLEY MACHINING STRATEGY
The cycle automatically controls the complete machining sequence from the first V groove to the final part-off operation.
For every programmed groove the cycle performs:
✅ Safe positioning
✅ Progressive roughing
✅ Full-retract pecking
✅ Left and right V-flank machining
✅ Automatic finishing
✅ Full clearance before repositioning
✅ Automatic movement to the next groove
The same machining strategy is repeated automatically until the required number of V grooves has been completed.
No need to manually program each groove individually.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🔨 FULL-RETRACT PECK MACHINING
Deep V grooves can create chip-control and tool-loading problems when the cutting tool remains buried in the component.
This cycle uses a controlled full-retract peck strategy.
After each cutting peck, the tool completely retracts outside the stock before returning for the next cutting movement.
This provides:
✅ Improved chip evacuation
✅ Better coolant access
✅ Reduced chip packing
✅ Reduced heat build-up
✅ Controlled deep-groove machining
✅ Improved tool clearance
✅ Reliable repetitive roughing
The complete pecking sequence is handled automatically by the cycle.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📐 PARAMETRIC V-GROOVE GEOMETRY
The V-pulley geometry is controlled directly from the required job dimensions.
The cycle automatically adapts to changes in:
✅ Pulley diameter
✅ Groove root diameter
✅ Groove bottom width
✅ Included V angle
✅ Groove position
Change the component dimensions and the machining cycle automatically adjusts to the new pulley configuration.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🔄 AUTOMATIC MULTI-GROOVE MACHINING
One of the main advantages of the cycle is automatic multiple-groove production.
The operator defines:
✅ First groove position
✅ Number of grooves
✅ Groove center spacing
The cycle automatically creates and machines the complete groove pattern.
Need 1 groove?
Set 1.
Need 3 grooves?
Set 3.
Need 5 grooves?
Set 5.
The cycle automatically positions and machines each identical V groove at the required spacing.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
↔️ AUTOMATIC GROOVE SPACING
There is no need to manually calculate every groove position.
Define the required center-to-center spacing and the cycle automatically positions each additional V groove.
This makes the same cycle reusable for:
✅ Single-groove pulleys
✅ Double-groove pulleys
✅ Triple-groove pulleys
✅ Multi-groove pulleys
✅ Custom pulley configurations
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
✨ AUTOMATIC V-GROOVE FINISHING
After the roughing sequence is complete, the cycle automatically finishes the V profile.
Both sides of the groove are machined as part of the stored finishing strategy.
This provides a complete operation from roughing through final V-profile machining without requiring a separately programmed finishing routine.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
✂️ AUTOMATIC FINAL PART-OFF
The cycle also includes an integrated automatic part-off operation.
The important sequence is:
Machine all V grooves → Finish all V grooves → Move to part-off position → Part off component
The part-off operation does not begin until the complete programmed V-pulley profile has been finished.
The final part-off position is independently adjustable for different component lengths.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🔨 PECK-STYLE PART-OFF
The part-off operation uses the same controlled full-retract machining principle.
The tool progressively cuts deeper while completely clearing the stock between pecks.
Benefits include:
✅ Improved chip removal
✅ Better coolant penetration
✅ Reduced tool loading
✅ Controlled deep parting
✅ Automatic progression to final cut-off
Once the programmed part-off depth is reached, the machining cycle is complete.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🧠 AUTOMATIC MACHINING CONTROL
From a compact set of job dimensions, the cycle automatically controls:
✅ V-groove geometry
✅ Groove depth
✅ Groove positions
✅ Groove quantity
✅ Groove spacing
✅ Left and right flank machining
✅ Progressive roughing
✅ Peck progression
✅ Tool clearance
✅ Finishing sequence
✅ Multi-groove indexing
✅ Final part-off positioning
✅ Part-off progression
The operator concentrates on the required component dimensions rather than rebuilding repetitive toolpaths.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🏭 BUILT FOR PRODUCTION
The Parametric Multi-Groove V-Pulley Machining Cycle is designed as a reusable production tool rather than a one-job CNC program.
Once configured and proven, the same cycle can be reused for different pulley configurations.
Ideal for:
✅ V-belt pulleys
✅ Multi-groove pulleys
✅ Drive pulleys
✅ Replacement pulleys
✅ Maintenance components
✅ Production components
✅ Prototype pulleys
✅ Repetitive grooving applications
✅ Custom pulley manufacturing
✅ CNC automation applications
✅ Repetitive production environments
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🌐 MULTI-CONTROLLER SUPPORT
Packages are available for:
✅ FANUC
✅ SIEMENS
✅ HAAS
✅ MAZAK
✅ MITSUBISHI
✅ OKUMA
✅ HEIDENHAIN
✅ FAGOR
✅ GSK
Controller-specific packages are supplied for supported CNC systems.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📦 COMPLETE DOWNLOAD PACKAGE
Package includes:
✅ Parametric Multi-Groove V-Pulley Machining Cycle
✅ Controller-ready CNC cycle
✅ Example calling program
✅ Complete user guide
✅ Complete training module
✅ Setup instructions
✅ Parameter explanation
✅ Machining-sequence explanation
✅ Full-retract peck explanation
✅ Multi-groove setup guidance
✅ Part-off setup guidance
✅ First-run prove-out procedure
✅ Controller-specific package
✅ Reusable production-cycle structure
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
💡 ONE CYCLE — MULTIPLE PULLEY CONFIGURATIONS
Different pulley diameter?
Change the job dimensions.
Different groove depth?
Change the root diameter.
Different V angle?
Change the groove geometry.
Need more grooves?
Change the quantity.
Different groove spacing?
Change the center spacing.
Different component length?
Change the part-off position.
The complete machining strategy remains stored inside the cycle.
No need to rebuild the complete CNC program every time the pulley changes.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🛒 AVAILABLE STANDALONE OR INSIDE CNC AUTOMATION PRO
The Parametric Multi-Groove V-Pulley Machining Cycle is available as a standalone downloadable package or as part of CNC Automation Pro.
CNC Automation Pro includes custom canned cycles, CNC macros, programming modules, software and CNC training resources.
CNC Automation Pro:
https://payhip.com/b/9IpYU
MacroMill CNC:
www.macromillcnc.com
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
PARAMETRIC MULTI-GROOVE V-PULLEY MACHINING CYCLE
One reusable cycle.
Multiple V grooves.
Automatic finishing.
Automatic part-off.
Built for reusable CNC production.
