FTTH / GPON Optical Link Budget & Unbalanced Splitter Cascade Calculator

Design, calculate, and certify FTTH / GPON / XGS-PON networks in minutes with this all-in-one Outside Plant (OSP) Engineering Suite.Built by telecom specialists for ISP/WISP owners, FTTH network planners, OSP engineers, and fiber splicing technicians. Runs 100% offline on any smartphone (Android/iOS) or PC + includes the unlocked Microsoft Excel Master Workbook.What's included in your instant download (.ZIP)?1. Standalone Offline Web Application (FTTH_Engineering_Suite_Pro.html): - Balanced GPON / XGS-PON Link Budget Calculator: Supports 1310 nm, 1490 nm, and 1550 nm wavelengths, B+/C+/C++ OLT SFP modules, fusion splices, SC/APC connectors, and 2-stage PLC splitters with automatic ITU-T G.984 pass/fail indicators. - Unbalanced Splitter Cascade Simulator (Asymmetric FBT Tap): Chain up to 16 FAT/NAP terminals using asymmetric couplers (5/95, 10/90, 15/85, 20/80, 25/75, 30/70, 40/60, 50/50) and inspect real-time pass-through trunk power and subscriber drop port Rx power. - OSP Bill of Materials (BOM) Calculator: Instantly calculate ADSS fiber cable length (+12% sag/slack), utility poles, suspension and tension clamps, stainless steel strapping band, buckles, and snowshoes. - TIA/EIA-598 Fiber Color Code Finder: Enter any fiber strand number (1 to 288) to instantly see the exact buffer tube color and strand color. - One-Click PDF Report Export: Print or save clean engineering reports for clients and project handovers.2. Editable Microsoft Excel Toolkit (FTTH_GPON_Engineering_Kit_Pro.xlsx): 4 pre-built worksheets with unlocked formulas ready for engineering proposals and RFPs.

---

FREQUENTLY ASKED QUESTIONS & TECHNICAL SPECS:

* How to calculate GPON / XGS-PON optical link budget? Automatically calculates attenuation at 1310nm, 1490nm, and 1550nm based on ITU-T G.984 standards.

* How to design an unbalanced splitter cascade (FBT asymmetric tap)? Simulates up to 16 NAP/FAT optical boxes using 5/95, 10/90, 15/85, 20/80, 25/75, 30/70, 40/60, and 50/50 splitters.

* Included templates: FTTH Link Budget Excel Spreadsheet (.xlsx), Outside Plant (OSP) Bill of Materials (BOM) calculator for ADSS cable, and TIA/EIA-598 fiber color code chart.
