A-Frame 70 — 86 m² house plan (PDF + DWG)

A-Frame 70: open-plan a-frame retreat, 86 m² (926 sq ft), 1 bedroom. Plan code G07.

You get a concept design set by residential designer George Trofimov: PDF drawings (floor plans, roof plan, sections, elevations, 3D views, window and door schedules) and DWG files. Metric drawings; imperial on request.

This is a concept design set, not construction drawings. Structural design, engineering, foundation, MEP and permit documents are not included: a local licensed professional must review and adapt the plan before construction. Licence for one build; the designer keeps copyright.

Plan page with all renders and sheets: https://geotrofimov.com/plans/a-frame-70-g07
