Outdoor LED Garden Spotlight 10W IP67 2700K
High-Performance Outdoor LED Garden Spotlight 10W IP67 – Warm White 2700K
The NE-IP67-10W-WW is a high-performance LED spotlight designed for outdoor garden lighting. It features a tiltable housing that provides directional illumination, ideal for enhancing the aesthetics and functionality of any outdoor space. Constructed with high-quality aluminum and glass, it offers a refined appearance combined with durability and weather resistance.
It emits safe, natural light with no flicker, glare, UV, or infrared radiation. With a wide 120° beam angle, it ensures broad and uniform lighting coverage. The warm white 2700K color temperature creates a comfortable ambiance for outdoor environments.
The unit is rated IP67, providing a high degree of protection against dust and water immersion, making it ideal for use in gardens, fountains, walkways, entrances, and architectural features. A transformer is required and must be selected from compatible options listed under accessories.
Technical Specifications – NE-IP67-10W-WW
Product Code: NE-IP67-10W-WW
Power Consumption: 10.0 W
Luminous Flux: 846 lumens
Luminous Efficacy: 84 lm/W
Color Temperature: 2700K (Warm White)
CCT Type: Single
Beam Angle: 120°
Light Directionality: Non-directional
CRI (Color Rendering Index): ≥80
R9 Index: 17
CRI Range: Min. 85 / Max. 24
Chromaticity: x = 0.323 / y = 0.353
Start Time: 0.1 seconds
Dimmable: No
Halogen Equivalent: 90 W
Energy Consumption: 10.0 kWh/1000h
Energy Class: G
Power Factor (PF): 0.8
Working Frequency: 50/60 Hz
Input Voltage: 12/24V AC
Driver Output Voltage: DC 18–23V
Connection Type: Terminal block
Operating Temperature Range: -40 ºC to +60 ºC
Switching Cycles: 100,000
Estimated Lifetime: 40,000 hours
Projected Lifespan:
– 3h/day: 36.52 years
– 5h/day: 21.91 years
– 8h/day: 13.69 years
Construction & Protection
Body Material: Aluminum
Diffuser: Transparent glass
Dimensions: Ø72 x 62 mm
Weight: 300 g
Ingress Protection Rating: IP67
Mounting Type: Surface or spike (user-defined)
Installation Notes: Transformer required (not included)
Certifications & Standards
Certified by: CE, RoHS, ISO9001
Applicable Standards:
IEC 62321:2008
EN 55015:2006
EN 61000-3-2:2006
EN 61000-3-3:2008
EN 61547:2009
EN 60598-1:2008
EN 61347-1:2008
EN 61347-2-13:2006
EN 62031:2008
Key Features
– Wide beam angle for area coverage
– Natural, flicker-free, UV- and IR-free light
– Suitable for humid and submerged environments
– Long service life with minimal maintenance
– Ideal for decorative and ambient outdoor use
– Requires external transformer (check accessories)
