Consultant expert, Dr. Muhammad Taha
ANAEROBIC REACTOR DEVELOPMENT
FOR COMPLEX ORGANIC WASTEWATER
A Thesis
The Faculty of Engineering
SCHOOL OF ENGINEERING
COCHIN UNIVERSITY OF SCIENCE AND TECHNOLOGY
KOCHI-682 022
2010
Certificate
Certified that this thesis entitled “Anaerobic Reactor Development for Com-
plex Organic Wastewater”, submitted to the Cochin University of Science and
Technology, Kochi for the award of Ph.D Degree, under the Faculty of Engi-
neering is the record of bonafide research carried out by Ajit Haridas, under
my supervision and guidance. This work did not form part of any dissertation
submitted for the award of any degree, diploma, associateship, fellowship or
other similar title or recognition from this or any other institution.
Prof. (Dr.) Babu. T. Jose
Supervising Guide,
Kochi –22, Faculty of Engineering.
31-07-2010. Cochin University of Science and Technology
Declaration
I, hereby declare that the work presented in the thesis en-
titled “Anaerobic reactor development for complex organic wastewater”, be-
ing submitted to Cochin University of Science and Technology for award of
Ph.D degree under the Faculty of Engineering, is the outcome of original
work done by me under the supervision of Dr. Babu T. Jose, Emeritus Pro-
fessor, School of Engineering, Cochin University of Science and Technology,
Kochi. This work did not form part of any dissertation submitted for the
award of any degree, diploma, associateship, fellowship or other similar
title or recognition from this or any other institution.
Kochi -22, Ajit Haridas
31-07-2010.
Anaerobic reactor development for complex organic wastewater
Synopsis
Anaerobic treatment is applied extensively of removal of organic pollutants (COD)
from wastewater. It is more competitive than aerobic treatment in applications where
the quantity of COD to be removed is large. The major fraction of COD is converted to
useful methane gas, and only a small fraction becomes waste sludge. The COD loading
rate of anaerobic reactors is higher than that of aerobic reactors and hence small reac-
tors are sufficient for the treatment of same quantity of COD.
Chapter 2 surveys anaerobic technology and identifies directions for improving re-
actor technology.
High-rate anaerobic reactors have reduced the cost of anaerobic treatment plants.
High-rate reactors routinely achieve organic loading rates 8 to 10 kg COD/ m3 reactor /
d and hydraulic retention times of the order of a few hours. High-rate reactor designs
can be broadly classified as fixed film (eg. fixed film, fluidized bed) and suspended
growth reactors (eg. UASB, EGSB). The fixed film reactors provide an inert carrier media
for growth of anaerobic consortia as a biofilm. Biomass is retained as settleable flocs or
granules in suspended growth reactors. The UASB is the most common reactor in use.
The CSTR is a suspended growth reactor but is not a high-rate reactor since there is no
mechanism to separate and retain biomass.
High-rate reactors have been successfully applied for the treatment of a wide range
of industrial and domestic wastewater. However, wastewaters containing degradable
COD in mostly particulate form, is not treatable at high-rate in these reactors. Such ef-
fluents are termed ‘complex organic wastewater’ in this thesis. Examples of such
wastewaters include dairy effluent, slaughterhouse effluent and palm oil mill effluent.
Municipal sewage can also be considered as complex organic wastewater. The devel-
opment of a high-rate anaerobic reactor capable of treatment of complex wastewater
is necessary.
This thesis concerns the development of a new high-rate anaerobic reactor called
the ‘Buoyant Filter Bioreactor – BFBR’ for the high-rate treatment of complex organic
wastewater. Current high-rate anaerobic reactors are based on the principle of decoup-
ling biomass retention times from the hydraulic retention times. This works only when
the rate limiting step in the reactor is a microbial growth process – typically acetoclastic
methanogenesis. In the treatment of complex wastewater, the rate limiting step is exo-
cellular enzymatic hydrolysis. The central hypothesis in the development of the BFBR is
that high-rate treatment of complex wastewater requires the decoupling of particulate-
COD retention time from the hydraulic retention time. Particulate COD, if retained suf-
ficiently long in the reactor should undergo complete conversion. The BFBR is designed
to retain particulates with the reactor using a deep-bed filter system.
Chapter 4 describes the development of BFBR. The BFBR has an upper chamber
and a lower chamber. Between the two chamber is a buoyant filter bed that filters the
reactor liquor. The filter media is made from expanded polystyrene beads. The feed
wastewater is pumped into the lower chamber which contains methanogenic sludge.
Gas produced accumulates in the lower chamber, while the liquor filters through the
buoyant filter bed into the upper chamber from where it
