Network Protocols Map — Digital Poster

Network Protocols Map

2009 Classic Edition · Revised 2026

Explore the layers and connections behind network communication—all in one map.

Organized around the seven-layer OSI model and the four-layer TCP/IP model, the Network Protocols Map brings together technologies for the Internet, LANs, WANs, wireless networking, voice communication, storage networks, and security. Its visual layout helps readers locate protocols within the network stack and understand their relationships.

Before 2010, Javvin sold tens of thousands of copies of this popular map. The 2026 revision preserves the classic structure while correcting terminology and technical descriptions, removing selected deprecated technologies, and introducing a softer color palette and a redesigned masthead.

The map features core TCP/IP technologies alongside historical protocol families such as NetWare, AppleTalk, and SNA, offering a perspective on the evolution of networking. Retained legacy technologies appear in gray. This is a revision of the classic map, rather than a comprehensive catalog of today's networking technologies.

A reference and display poster for networking students, educators, engineers, and technology history enthusiasts—suited to classrooms, study areas, and workspaces.

Digital download · Landscape, 36 × 24 inches (approx. 91.4 × 61 cm) · High-resolution 300 DPI PDF · Ready to print and frame

English-language poster. Digital download; no physical item shipped.

Printing & use — Personal use: up to 2 printed copies, displayed in one place. Institutions: one license per location. Commercial use: contact us. Full terms: https://javvincompany.github.io/en/about.html#license

网络协议全景图

2009 经典版 · 2026 修订

一张图，梳理网络通信的层次与脉络。

注意：本图谱为英文版，暂无中文版。

《网络协议全景图》以 OSI 七层模型与 TCP/IP 四层模型为框架，汇集互联网、局域网、广域网、无线网络、语音通信、存储网络及安全相关技术，直观呈现协议的层级位置与相互关系。

2010 年之前，Javvin 已售出数万份这款图谱，深受读者欢迎。2026 年修订版保留经典版的整体结构，校订文字与技术表述，移除部分已弃用技术，并以更柔和的配色和全新标题设计呈现。

图中既有 TCP/IP 等核心技术，也保留 NetWare、AppleTalk、SNA 等历史协议家族，帮助读者理解网络技术的发展脉络。保留的历史技术以灰字标示。本图是经典图谱的修订版，并非覆盖当今所有网络技术的完整清单。

适合网络技术学习者、教师、工程师及科技史爱好者，用于教学、学习参考与空间展示。

电子下载 · 横版 36 × 24 英寸（约 91.4 × 61 厘米）· 300 DPI 高清 PDF · 可自行打印装裱

图谱内容为英文，下载后可自行打印；不寄送实体海报。

打印与使用——个人使用：打印不超过 2 份，限一处展示。机构多点使用：每个点购买一份授权。商用：请联系我们。完整条款：https://javvincompany.github.io/zh/about.html#license
