✅ For those who do not have SolidWorks Toolbox.
✅ SolidWorks version 2017-2024 files with configurations for each fastener.
✅ You will also find instructions on how to edit the custom properties of files to display them correctly in the BOM table.
🚀 What's Inside:
✅ Anchors
FH II B (Fischer Anchor Bolt)
✅ Retaining rings
Lock washers DIN 6799
Retaining ring DIN 472
✅ Hooks
O-hook
✅ Pins
Parallel pin ISO 2338 (DIN 7)
Split pin ISO 1234 (DIN 94)
✅ Gears
Helical gear generator
Spur gear generator
✅ Wood screws
Wood screw DIN 571
Wood screw DIN 7997-H
✅ Keys
Parallel key DIN 6885-A
✅ Washers
Plain washer ISO 7089 (DIN 125-A)
Plain washer ISO 7090 (DIN 125-B)
Plain washer ISO 7091 (DIN 126)
Plain washer ISO 7092 (DIN 433)
Plain washer ISO 7093-1 (DIN 9021)
Spring lock washer DIN 137-B
✅ Self-tapping screws
Self-tapping screw ISO 7050-C-H (DIN 7982-C)
✅ Screws
Drilling screw ISO 15480
Screw DIN 967
Screw ISO 10462 (DIN 7991)
Screw ISO 1207 (DIN 84)
Screw ISO 1580 (DIN 85)
Screw ISO 2009 (DIN 963)
Screw ISO 2010 (DIN 964)
Screw ISO 4762 (DIN 912)
Screw ISO 7045 (DIN 7985)
Screw ISO 7046-1 (DIN 965)
Screw ISO 7047 (DIN 966)
Screw ISO 7380-FL
Screw ISO 7380
Set screw DIN EN 24766 (DIN 551)
Set screw DIN EN 27435 (DIN 417)
Set screw ISO 4026 (DIN 913)
Set screw ISO 4027 (DIN 914)
Set screw ISO 4028 (DIN 915)
Set screw ISO 4029 (DIN 916)
Shoulder screw ISO 7379
Thumb screw DIN 464
✅ Screwed insert
Slotted insert DIN 7965
✅ Threaded Rods & Studs
Threaded rod DIN 976-1
✅ Bolts
Bolt DIN 603 (ISO 8677)
Bolt DIN 608
Bolt DIN EN 1665 (DIN 6921)
Bolt DIN EN 24017 (DIN 933)
Bolt DIN EN 24018 (DIN 558)
Bolt ISO 4014 (DIN 931)
Lifting eye bolt DIN 580
Round wing bolt DIN 316-D
U-bolt DIN 3570
✅ Nuts
Castle nut DIN 935 (ISO 7035)
Castle nut DIN 937
Collar nut DIN 6331
Domed cap nut DIN 1587
Flange nut DIN EN 1661 (DIN 6923)
High nut DIN 6334
Lifting eye nut DIN 582
Nut DIN EN 24032 (DIN 934)
Nut ISO 10511 (DIN 985)
Round wing nut DIN 315-D
Thin nut DIN EN 24035 (DIN 439-B)
