V-387The Queen| Luxury modern duplex house plan, 3 Bedroom + 3 Bathroom, 3 Family, 1 Dinning, 3 Balcony, 1 Porch, 2 Car Garage,.

V-387 The Queen

------------------

House Description:

Bedroom 3 Nos.

Bathroom 3 Nos.

Garage 2 Cars

Living 1 Nos.

Dinning    1 No.

Family Setting 1 No.

Media / Theatre 1 No.

Porch 1 No.

Balcony     2 Nos.

Terrace     1 No. .

Laundry     1 No.

Footprint WxL 10.9 x 15.3 Meter 36 x 50 Feet

Total Area 288 M2 = 3100 F2

------------------

Drawing Description:

Floor Plan 2 Nos.

Elevation Plan 2 Nos.

Roof Location 1 No.

3D Rendering 1 No.

Furniture's Layout 2 Nos.

Section Plan 1 No.

Typical Details 1 No.

Columns Grid 1 No.

Roof Deck Plan 1 No.

D & W Schedule 1 No.

------------------

* General Notes:

1- We are selling all our house plans as PDF digital file only, Nothing will be sent by post.

2- You will get Two sets of detailed drawings as PDF file, in both units (Feet-inch & Meter-cm).

3- Please print using (A2 or A3) paper size only, Don't print as A4 size.
