DEVELOPED SECTION for AutoCAD or BricsCAD, perpetual version

On Sale
Added to cart
An add-on for AUTOCAD or BricsCAD, which determines the developed (unfolded) section of one set of 3DSOLID, 3DMESH or 3DFACE entities and vertical plans passing through a 2D POLYLINE which may contain arcs. You can actually make the section along any curve. Section can be wrapped or unwrapped.

There is another command that generates drawings in PDF format, for several rectangular areas from DWG. Without this new command you would have wasted time, manually entering the PLOT command and its options, in repeatedly.
You will get a ZIP (1MB) file
