Modify longitudinal profile AutoLisp source

On Sale
$83.00
$83.00
Added to cart
3 new commands are introduced in AutoCAD or programs based on IntelliCAD, such as BricsCAD, ProgeCAD, ActCAD, ZWCAD, etc., useful for designers:
  • YTE: changes the Y texts of some points, relative to an origin point,
  • XTE: changes the X text of some points, relative to X=0 of the current UCS,
  • PTE: inserts elevation and slope with triangle on a POLYLINE.
The commands increase productivity in the modification of longitudinal or transversal profiles from the design of roads and civil constructions.

You are licensed to use this "Modify longitudinal profile AutoLisp source", for drawing or to include it in your programs that you sell.
You will get the following files:
  • LSP (12KB)
  • PDF (105KB)
  • PDF (243KB)
  • DWG (25KB)
  • DWG (26KB)
  • DWG (25KB)
  • DWG (25KB)
  • DWG (25KB)
  • DWG (25KB)
  • DWG (79KB)
